Best AI Tools for SolidWorks and SolidWorks PDM (2026)

Best AI Tools for SolidWorks and SolidWorks PDM (2026)

Best AI Tools for SolidWorks and SolidWorks PDM (2026)

SolidWorks AI tools compared for teams: AURA, LEO, desktop helpers and PDM search, with token limits, platform needs and a two-week test plan.

·

⏱

5 min read

Michelle Ben-David

Product Specialist, Leo AI

Product Specialist, Leo AI

Mechanical Engineer, B.Sc. · Ex-Officer, Elite Tech Unit · Aerospace & Defence · Medical Devices

Mechanical Engineer, B.Sc. · Ex-Officer, Elite Tech Unit · Aerospace & Defence · Medical Devices

Michelle Ben-David is a mechanical engineer and Technion graduate. She served in an IDF elite technology and intelligence unit, where she developed multidisciplinary systems integrating mechanics, electronics, and advanced algorithms. Her engineering background spans robotics, medical devices, and automotive systems.

Cover image illustrating Best AI Tools for SolidWorks and SolidWorks PDM (2026): SolidWorks AI tools compared for teams: AURA, LEO, desktop helpers and PDM search, with token limit

BOTTOM LINE

Use AURA and LEO for help inside SOLIDWORKS Design, and a search layer for parts already in your vault. Dassault includes the companions in every commercial Design license but meters them in tokens: 2,000 per license, granted once. Test each option on your own files for two weeks. Leo AI is the search option in this comparison.

Pick the SolidWorks AI tool by the data it reads. Dassault's AURA and LEO companions work inside SOLIDWORKS Design on the open model, while a search layer reads the files and PDM vault your team already stores. Modeling help and finding past parts are different jobs, so test each tool on its own task.

If you manage 12 SolidWorks seats on one PDM vault, you are buying for three jobs: modeling help, assembly generation, and finding parts that already exist. The table below shows what each option reads, how it is metered, and who can see the results.

Four criteria separate SolidWorks AI tools for a team

One user can try any tool. A team of 12 needs four answers before a pilot.

Token math for a 12-seat team, using the Dassault token article:

  1. Licenses: 12 SOLIDWORKS Design seats.

  2. Grant per license: 2,000 tokens, given once, with no renewal.

  3. Team total: 12 x 2,000 = 24,000 tokens.

  4. Price per task: not published, so log it during the trial.

IN PRACTICE

The geometry search has been invaluable, helping me find standard parts instead of designing new ones, saving a huge amount of time and effort. The search system is smart and CAD-aware.

- eytan s., R&D Engineer

Four SolidWorks AI options, side by side

The table lists what each option does, where it runs, the data it reaches, its team features and who it suits. Facts come from the Dassault and Leo pages linked under Sources.

Option

What it does

Runs in

Data it reaches

Team features

Best for

SOLIDWORKS AURA

Connects users with knowledge and answers questions about the active design, assembly or project

SOLIDWORKS with Cloud Services, via the 3DEXPERIENCE platform

Active design, assembly or project; web knowledge

Included with commercial Design licenses; token metered

Engineers who need a modeling answer in session

SOLIDWORKS LEO

Generates assembly structures from prompts; handles mesh conversion, simulation studies, assembly evaluation and error resolution

SOLIDWORKS Design

The model open in the session

Same license and token model as AURA

Starting assemblies and fixing model errors

SOLIDWORKS desktop helpers (Command Predictor, Auto-Fastener, Sketch Repair)

Predicts the next command, recognizes fasteners and reduces repetitive sketch work

SOLIDWORKS Design

The current task and sketch history

Included with commercial Design licenses; no detail on metering

Daily modeling speed

Leo AI

Finds existing parts by description, shape or function across PLM and PDM, and shows its reasoning

Cloud service; source files stay in PDM, PLM or drives

SolidWorks PDM, other PLM systems, network drives; native CAD

SOC 2 Type II; customer files not used for training

Part reuse and retrieval across a shared vault

Name check: SOLIDWORKS LEO is a Dassault Virtual Companion. Leo AI is a separate product from a different company.

How each option measures against the criteria

Each option was assessed from vendor documentation read on 2026-10-30. No hands-on testing is claimed here.

AURA. Dassault lists it as "Available today with Cloud Services." It gives knowledge and answers, and Dassault gives the building tasks to LEO. The open points for a team are the Cloud Services tier and how many tokens a question costs.

LEO. Its documented jobs are assembly structures, mesh conversion, simulation studies, assembly evaluation and error resolution. Dassault lists it as "Available today with capabilities expanding through 2026 and beyond," so the feature list will change. Pilot it on one assembly whose released structure you already know, then compare the hierarchies.

Desktop helpers. Command Predictor, Auto-Fastener, What's Wrong Analysis and Sketch Repair appear on the AI overview page with no further detail. Measure them by clicks saved per task during the trial, because the page gives no figures.

The search layer. It reads vault files rather than the open model, so its test is retrieval accuracy and permissions, not modeling speed. The last section covers that test. The geometric search post shows how shape queries differ from keyword queries.

Run a two-week test on your own SolidWorks files

Use your own parts and assemblies, not vendor demos. Each step has a pass criterion you set before the test starts.

  1. Day 1: pick 20 parts from the vault that engineers re-modeled in the past year. Write each as the one-line description an engineer would type.

  2. Days 2 to 4: run the 20 descriptions in each search tool. Pass: the correct part appears in the top 5 results for at least 16 of 20.

  3. Days 5 to 7: give LEO the specification of one assembly with 30 or more components. Pass: the generated hierarchy matches the released one with no more than 3 manual corrections.

  4. Days 8 to 10: record tokens used for 10 typical tasks. Multiply by the tasks your team runs per month and compare with the 24,000-token grant from the math above.

  5. Day 11: sign in as a user with no access to one restricted folder. Pass: no part from that folder appears in any answer.

  6. Days 12 to 14: have two engineers score each tool on time saved per task. Drop any tool that fails steps 2, 3 or 5.

For safety-critical parts, a licensed engineer still reviews every generated or retrieved result before release.

Finding past parts in SolidWorks PDM with Leo AI

For step 2 of the test, give Leo AI the same 20 descriptions. Leo offers integrations with leading PDM and PLM platforms, SolidWorks PDM among them, and its AI for CAD page lists SolidWorks under CAD tools.

An engineer types the requirement in words, or uses "Search by shape or function." Leo returns matching parts across PLM and PDM "with the reasoning behind it," so the reviewer sees why each part ranked. Leo converts your data into non-reversible encrypted vectors stored in GCP and keeps no original files; see the security page for the full data handling.

One limit: Leo's public pages do not describe how SolidWorks PDM permissions map to results, so run the permissions step on day 11 first. For tools that work on the vault itself, see the SolidWorks PDM tool comparison.

FAQ

Yes. Dassault states that access to SOLIDWORKS AI capabilities and Virtual Companions is included with every commercial SOLIDWORKS Design license. The companions are AURA and LEO, and usage is metered in tokens.

It depends on the job. For help while modeling, use the companions built into SOLIDWORKS Design. For finding parts that already exist in a PDM vault, test a search layer on 20 known duplicates before you decide.

Dassault's AI overview says to connect to the 3DEXPERIENCE platform to access included SOLIDWORKS AI features, and lists AURA as available with Cloud Services. Confirm your license tier with your reseller before a pilot.

Dassault's August 2026 blog says each SOLIDWORKS Design or Design with Cloud Services license includes 2,000 tokens, granted once. These free tokens do not renew, and more can be bought online or through a reseller.

SOLIDWORKS LEO is a Dassault Virtual Companion that works inside SOLIDWORKS Design. Leo AI is a separate product that searches parts across PDM, PLM and drives, and shows the reasoning behind each match.

Dassault lists Intent to CAD, which turns natural language, CAD files, scans and legacy drawings into editable parametric models. Check each result against your drawing and design rules before release.

  1. AI Product Design with Embedded AI Tools, Dassault Systemes SOLIDWORKS, accessed 2026-10-30

  2. SOLIDWORKS Design AI Virtual Companions, Dassault Systemes SOLIDWORKS, accessed 2026-10-30

  3. SOLIDWORKS AI 101: Understanding How Tokens Work, Dassault Systemes SOLIDWORKS blog, 2026-08-13, accessed 2026-10-30

  4. Security, Leo AI, accessed 2026-10-30

  5. AI for CAD, Leo AI, accessed 2026-10-30
